Edge Profiling & Polishing
LP-8 Polisher
by Lithocore
Automatic straight-line edge polisher that takes a sawn edge to a finished profile in one pass.
8 automatic polishing spindles
Spindles
Bullnose, half-bullnose, ogee, bevel, flat-polish (interchangeable tooling)
Edge profiles
10 - 80 mm (0.4" - 3.1")
Thickness range
Not sure if the LP-8 Polisher is right for your application?
Our AI can help you compare machines, find parts, and explore your options.
Ideal For
- Fabricators finishing edges in-house instead of outsourcing
- Shops standardizing on a small set of edge profiles
- Slate and stone flooring producers
Spindles
8 automatic polishing spindles
Edge profiles
Bullnose, half-bullnose, ogee, bevel, flat-polish (interchangeable tooling)
Thickness range
10 - 80 mm (0.4" - 3.1")
Conveyor speed
0.5 - 3 m/min (1.6 - 9.8 ft/min), variable
Key Features
LP-8 Polisher Features
Standard features that set this machine apart in demanding manufacturing environments.
Precision & Performance
- 8 automatic polishing spindles with a graduated grit sequence
- Variable conveyor speed for material and finish control
Ease of Operation
- Lithocore Vein control with a saved recipe library
- Automatic thickness sensing
Built-In Extras
- Quick-change tooling for profile changeover
- Recirculating water and slurry management
Full Specifications
Lithocore LP-8 Polisher Technical Details
Complete specifications, standard features, and optional upgrades.
- Spindles
- 8 automatic polishing spindles
- Edge profiles
- Bullnose, half-bullnose, ogee, bevel, flat-polish (interchangeable tooling)
- Thickness range
- 10 - 80 mm (0.4" - 3.1")
- Conveyor speed
- 0.5 - 3 m/min (1.6 - 9.8 ft/min), variable
- Motor power (total)
- 22 kW (30 HP) across 8 spindles
- Water system
- Recirculating, 600 L tank
- Positioning accuracy
- ±0.1 mm (0.004") edge alignment
- Control
- Lithocore Vein control, 15" touchscreen
- Power requirement
- 400V/3-phase, 63A
- Footprint
- 6.0 x 1.8 m (20' x 6')
| Spindles | 8 automatic polishing spindles |
| Edge profiles | Bullnose, half-bullnose, ogee, bevel, flat-polish (interchangeable tooling) |
| Thickness range | 10 - 80 mm (0.4" - 3.1") |
| Conveyor speed | 0.5 - 3 m/min (1.6 - 9.8 ft/min), variable |
| Motor power (total) | 22 kW (30 HP) across 8 spindles |
| Water system | Recirculating, 600 L tank |
| Positioning accuracy | ±0.1 mm (0.004") edge alignment |
| Control | Lithocore Vein control, 15" touchscreen |
| Power requirement | 400V/3-phase, 63A |
| Footprint | 6.0 x 1.8 m (20' x 6') |
- 8 automatic polishing spindles with a graduated grit sequence
- Quick-change tooling for profile changeover
- Variable conveyor speed for material and finish control
- Lithocore Vein control with a saved recipe library
- Recirculating water and slurry management
- Automatic thickness sensing
- Additional spindle station for finer grit progression
- Chamfering attachment
- Automatic infeed/outfeed roller tables
- Countertop edge finishing
- Slate flooring and cladding edge polishing
- Vanity and tabletop edge profiling
- Stair tread and threshold edge finishing
FAQ
LP-8 Polisher Questions
Answers to common questions about the LP-8 Polisher.
Quick-change tooling lets your operator swap profile wheels between jobs without a lengthy setup, so a mixed order of profiles can run in one shift.
Granite, quartz, marble, engineered stone and slate within the listed thickness range.
A 400V/3-phase, 63A service, plus a water supply for the recirculating tank.
The polisher, standard profile tooling set, Lithocore Vein control, rigging and installation, and operator training.
