Metal 3D Printing
LP-400 Dual
by Layerion
Dual-laser powder-bed fusion printer doubling build rate on a larger production envelope.
400 x 400 x 450 mm (15.7 x 15.7 x 17.7 in)
Build volume
2 x 500 W fiber lasers, overlapping scan fields
Laser configuration
20 - 60 μm
Layer thickness
Not sure if the LP-400 Dual is right for your application?
Our AI can help you compare machines, find parts, and explore your options.
Ideal For
- Shops moving from prototyping into production volume
- Larger single components needing more build envelope
- Multi-part nested batch production
- Customers already qualified on an LP-250 scaling up capacity
Build volume
400 x 400 x 450 mm (15.7 x 15.7 x 17.7 in)
Laser configuration
2 x 500 W fiber lasers, overlapping scan fields
Layer thickness
20 - 60 μm
Minimum spot size
80 μm
Key Features
LP-400 Dual Features
Standard features that set this machine apart in demanding manufacturing environments.
Ease of Operation
- Closed-loop powder handling to minimize operator exposure
- Automated inert-gas purge and oxygen monitoring
- Layerion Forma control with shared material library across the Layerion line
- Integrated melt-pool monitoring with per-laser quality tracking
Built-In Extras
- Build-plate heating for reduced residual stress on large parts
- Dual 500 W fiber lasers with overlapping scan fields for full-plate coverage
- Nearly double the build rate of the single-laser LP-250
Full Specifications
Layerion LP-400 Dual Technical Details
Complete specifications, standard features, and optional upgrades.
- Build volume
- 400 x 400 x 450 mm (15.7 x 15.7 x 17.7 in)
- Laser configuration
- 2 x 500 W fiber lasers, overlapping scan fields
- Layer thickness
- 20 - 60 μm
- Minimum spot size
- 80 μm
- Max scan speed
- up to 7 m/s per laser
- Build rate
- up to 70 cm³/hr
- Positioning accuracy
- ±25 μm
- Process atmosphere
- Argon or nitrogen, O2 < 100 ppm
- Compatible powders
- Stainless steel, tool steel, titanium, nickel superalloys, aluminum, copper alloys
- Control
- Layerion Forma control
| Build volume | 400 x 400 x 450 mm (15.7 x 15.7 x 17.7 in) |
| Laser configuration | 2 x 500 W fiber lasers, overlapping scan fields |
| Layer thickness | 20 - 60 μm |
| Minimum spot size | 80 μm |
| Max scan speed | up to 7 m/s per laser |
| Build rate | up to 70 cm³/hr |
| Positioning accuracy | ±25 μm |
| Process atmosphere | Argon or nitrogen, O2 < 100 ppm |
| Compatible powders | Stainless steel, tool steel, titanium, nickel superalloys, aluminum, copper alloys |
| Control | Layerion Forma control |
- Dual 500 W fiber lasers with overlapping scan fields for full-plate coverage
- Nearly double the build rate of the single-laser LP-250
- Closed-loop powder handling to minimize operator exposure
- Automated inert-gas purge and oxygen monitoring
- Layerion Forma control with shared material library across the Layerion line
- Build-plate heating for reduced residual stress on large parts
- Integrated melt-pool monitoring with per-laser quality tracking
- Extended material qualification package for exotic alloys
- Automated powder sieving and recycling station
- Advanced melt-pool monitoring with per-layer quality reports
- Wire-EDM-ready build plate for easy part removal
- Production-volume printing of qualified parts
- Large single-component printing beyond the LP-250's envelope
- Multi-part nested builds for batch production
- Copper alloy thermal-management component printing
FAQ
LP-400 Dual Questions
Answers to common questions about the LP-400 Dual.
Roughly double the build rate thanks to the two overlapping lasers, though actual throughput depends on part geometry and how many parts you nest per build — our applications engineers can estimate cycle time on your specific parts.
Yes, both machines share the Layerion Forma control and material parameter library, so a process qualified on the LP-250 transfers directly rather than requiring requalification from scratch.
Typically 14-16 weeks build-to-order given the dual-laser optical system; we confirm your exact ship date once your configuration and material qualification needs are finalized.
Yes — we can quote a complete workflow including stress-relief heat treatment, support removal and finish machining on critical surfaces alongside your printer purchase.
