Swiss-Type Lathes
JS-32
by Jurassa
32 mm-capacity Swiss-type lathe with 9 axes and back-working for complex small parts.
32 mm (1.26 in)
Max bar diameter
450 mm (17.7 in)
Max turning length (guide bushing mode)
8,000 rpm
Main spindle speed
Not sure if the JS-32 is right for your application?
Our AI can help you compare machines, find parts, and explore your options.
Ideal For
- Shops whose Swiss-type parts have grown past 20 mm diameter
- Complex parts needing Y-axis milling or extended back-working
- High-mix precision component manufacturers
- Buyers upgrading from a JS-20 without changing process knowledge
Max bar diameter
32 mm (1.26 in)
Max turning length (guide bushing mode)
450 mm (17.7 in)
Main spindle speed
8,000 rpm
Sub-spindle speed
8,000 rpm
Key Features
JS-32 Features
Standard features that set this machine apart in demanding manufacturing environments.
Precision & Performance
- 9-axis configuration with Y-axis for off-center milling
- Expanded back-working tool set on the sub-spindle
Ease of Operation
- Jurassa Corvo control with Swiss-specific cycle library
- Remote diagnostics port
Cutting Capability
- 32 tool positions including 8 driven stations
- Coolant-through-tool plumbing on driven stations
Built-In Extras
- Switchable guide bushing / bushingless operation
- Standard bar feeder interface for unattended running
Full Specifications
Jurassa JS-32 Technical Details
Complete specifications, standard features, and optional upgrades.
- Max bar diameter
- 32 mm (1.26 in)
- Max turning length (guide bushing mode)
- 450 mm (17.7 in)
- Main spindle speed
- 8,000 rpm
- Sub-spindle speed
- 8,000 rpm
- Total axes
- 9, including Y-axis and back-working
- Tool positions
- 32
- Driven tool stations
- 8, up to 8,000 rpm
- Guide bushing
- Adjustable, switchable to bushingless mode
- Bar feeder interface
- Standard
- Positioning accuracy
- ±0.004 mm (0.00016 in)
- Repeatability
- ±0.002 mm (0.00008 in)
- Control
- Jurassa Corvo control
| Max bar diameter | 32 mm (1.26 in) |
| Max turning length (guide bushing mode) | 450 mm (17.7 in) |
| Main spindle speed | 8,000 rpm |
| Sub-spindle speed | 8,000 rpm |
| Total axes | 9, including Y-axis and back-working |
| Tool positions | 32 |
| Driven tool stations | 8, up to 8,000 rpm |
| Guide bushing | Adjustable, switchable to bushingless mode |
| Bar feeder interface | Standard |
| Positioning accuracy | ±0.004 mm (0.00016 in) |
| Repeatability | ±0.002 mm (0.00008 in) |
| Control | Jurassa Corvo control |
- 9-axis configuration with Y-axis for off-center milling
- Expanded back-working tool set on the sub-spindle
- Switchable guide bushing / bushingless operation
- 32 tool positions including 8 driven stations
- Jurassa Corvo control with Swiss-specific cycle library
- Standard bar feeder interface for unattended running
- Coolant-through-tool plumbing on driven stations
- Remote diagnostics port
- Extended sub-spindle back-working tool set
- Automatic part-length measurement probe
- High-pressure coolant upgrade, 40 bar
- Chip conveyor for high-volume swarf
- Parts catcher and sorting conveyor
- Hydraulic and pneumatic fitting components
- Larger medical and surgical instrument parts
- Precision automotive fasteners and connectors
- Complex small parts needing off-center milled features
FAQ
JS-32 Questions
Answers to common questions about the JS-32.
The JS-32 handles larger 32 mm bar stock, adds a Y-axis and two more axes overall for more complex off-center features, and has more driven tool stations — it's the step up once your parts outgrow the JS-20's 20 mm capacity or need more complex milling.
Yes — the Jurassa Corvo control and Swiss-type programming logic are shared across both machines, so operators trained on a JS-20 need only a short orientation on the added Y-axis and back-working capability.
Typically 12-14 weeks build-to-order; we confirm your exact ship date once your configuration is finalized at quote stage.
Tollaston works with equipment lenders on term loans and lease-to-own plans; your sales rep can provide side-by-side numbers alongside your quote.
