CO2 Laser Cutting & Engraving
FC-2030
by Formavex
Wide-bed 300W CO2 laser for production sign, display and packaging cutting and engraving.
2000 x 3000 mm (79" x 118")
Bed size
300 W in-house sealed CO2 laser tube
Laser power
25 mm (1")
Max cut thickness, acrylic
Not sure if the FC-2030 is right for your application?
Our AI can help you compare machines, find parts, and explore your options.
Ideal For
- Sign shops running production volumes
- Shops needing a wide bed for full sign panels
- Businesses combining cutting and engraving in one job
Bed size
2000 x 3000 mm (79" x 118")
Laser power
300 W in-house sealed CO2 laser tube
Max cut thickness, acrylic
25 mm (1")
Max cut thickness, plywood/MDF
18 mm (0.7")
Key Features
FC-2030 Features
Standard features that set this machine apart in demanding manufacturing environments.
Ease of Operation
- Formavex EdgeLogic control with combined cut-and-engrave job files
- Auto-focus laser head
- Red-dot pointer for job alignment
Safety & Reliability
- Honeycomb vacuum bed with dual-zone hold-down
- Camera-assisted registration for pre-printed material
- Dual-zone fume extraction ducting
Built-In Extras
- Job-time estimation before running the file
Full Specifications
Formavex FC-2030 Technical Details
Complete specifications, standard features, and optional upgrades.
- Bed size
- 2000 x 3000 mm (79" x 118")
- Laser power
- 300 W in-house sealed CO2 laser tube
- Max cut thickness, acrylic
- 25 mm (1")
- Max cut thickness, plywood/MDF
- 18 mm (0.7")
- Engraving resolution
- Up to 1000 DPI
- Max positioning speed
- 60 m/min (2,362 in/min)
- Positioning accuracy
- ±0.05 mm (0.002")
- Bed type
- Honeycomb vacuum bed, dual-zone
- Control
- Formavex EdgeLogic control, 21" touchscreen
- Exhaust requirement
- Dual-zone extraction, minimum 1,200 CFM
- Power requirement
- 208-240V, single-phase, 30A service
- Footprint
- 4.2 x 3.6 m (14' x 12')
| Bed size | 2000 x 3000 mm (79" x 118") |
| Laser power | 300 W in-house sealed CO2 laser tube |
| Max cut thickness, acrylic | 25 mm (1") |
| Max cut thickness, plywood/MDF | 18 mm (0.7") |
| Engraving resolution | Up to 1000 DPI |
| Max positioning speed | 60 m/min (2,362 in/min) |
| Positioning accuracy | ±0.05 mm (0.002") |
| Bed type | Honeycomb vacuum bed, dual-zone |
| Control | Formavex EdgeLogic control, 21" touchscreen |
| Exhaust requirement | Dual-zone extraction, minimum 1,200 CFM |
| Power requirement | 208-240V, single-phase, 30A service |
| Footprint | 4.2 x 3.6 m (14' x 12') |
- Formavex EdgeLogic control with combined cut-and-engrave job files
- Honeycomb vacuum bed with dual-zone hold-down
- Auto-focus laser head
- Red-dot pointer for job alignment
- Camera-assisted registration for pre-printed material
- Dual-zone fume extraction ducting
- Job-time estimation before running the file
- Rotary attachment for cylindrical engraving
- Roll-feed material handling for continuous stock
- Second exhaust blower for high-volume shops
- Extended warranty package on the laser tube
- Sign and display fabrication
- Point-of-purchase and retail fixtures
- Packaging prototypes and short-run boxes
- Awards, plaques and personalized gifts
FAQ
FC-2030 Questions
Answers to common questions about the FC-2030.
Typically 6-8 weeks from order; we confirm the exact date at order.
A 208-240V single-phase, 30A service, and dual-zone exhaust ducting rated at least 1,200 CFM to the outside. We assess your ventilation during the site survey.
Yes — on-site training covers job setup, material presets and the cut-and-engrave workflow.
Base machine, Formavex EdgeLogic control, exhaust connection kit, rigging and installation, and operator training.
