230 mm
Largest profile handled
8 m
Longest bar length
2
Sizes to match your job mix
Not sure which tube laser cutting is right for you?
Our AI can help you compare machines, find parts, and explore your options.
Advantages
Why Choose Tube Laser Cutting?
One setup, every feature
Holes, slots, notches and miters cut in a single program, replacing separate sawing and drilling steps.
Remnant-minimizing nesting
The Lasoryx Vector control nests your cut list against real bar lengths to cut drop and waste.
Proven on your own tube
We run a live test cut on your actual profile mix at the Tech Centre before you buy.
Coast-to-coast service
Technicians and stocked consumables across Canada and the US keep your tube laser running.
Featured
LXT-230
Heavy-duty tube laser cutting round, square and rectangular profile up to 230 mm across.
Lasoryx LXT-230
Tube diameter range (round)
20 - 230 mm (0.8" - 9")
Square/rectangular profile range
20 x 20 mm to 200 x 200 mm (0.8" - 7.9")
Max bar length
8 m (26')
Max bar weight
40 kg/m (27 lb/ft)
Our Machines
The Complete Tube Laser Cutting Lineup
Each system is engineered for specific applications. Compare specs to find the right fit.
Tube laser cutting system
LXT-230
The LXT-230 cuts round, square, rectangular and angle profile from 20 mm up to 230 mm (0.8" to 9") across in a single setup — holes, slots, notches and compound miters programmed straight from your 3D model, with no secondary drilling or sawing. A 6 kW in-house fiber laser source and automatic bar loader feed stock up to 8 m (26') long, and a self-centring chuck handles heavy structural profile without hand-adjustment between runs. The Lasoryx Vector control runs tube-specific nesting that minimizes remnant length on every bar. Tollaston programs your first parts, runs a test cut on your own tube stock at the Vaughan Tech Centre, and trains your team on setup and nesting before handover.
- Tube diameter range (round)
- 20 - 230 mm (0.8" - 9")
- Square/rectangular profile range
- 20 x 20 mm to 200 x 200 mm (0.8" - 7.9")
- Max bar length
- 8 m (26')
- Max bar weight
- 40 kg/m (27 lb/ft)
Tube laser cutting system
LXT-65
The LXT-65 brings tube laser cutting to shops that don't need the LXT-230's heavy-profile capacity. It cuts round, square and rectangular tube from 12.7 mm up to 65 mm (0.5" to 2.6") across, handling holes, slots, notches and miters in one setup instead of a separate saw and drill press operation. A 3 kW in-house fiber laser source and a single-chuck loading table suit lower-volume shops or those running a wide mix of small structural and architectural tube. The Lasoryx Vector control's tube nesting minimizes drop from every bar. Tollaston commissions the LXT-65 on your own tube stock, trains your team on setup, and backs it with the same coast-to-coast parts and service network as every Lasoryx we sell.
- Tube diameter range (round)
- 12.7 - 65 mm (0.5" - 2.6")
- Square/rectangular profile range
- 10 x 10 mm to 60 x 60 mm (0.4" - 2.4")
- Max bar length
- 6.5 m (21')
- Max bar weight
- 20 kg/m (13 lb/ft)
See everything we carry from Lasoryx.
Side by Side
Compare Systems
See how each platform stacks up across the specs that matter most.
LXT-230Featured
- Best for
- Heavy structural profile
- Tube diameter range
- 20 - 230 mm
- Max bar length
- 8 m (26')
- Laser power
- 6 kW
- Loading
- Automatic bar loader
LXT-65
- Best for
- Job shops, architectural tube
- Tube diameter range
- 12.7 - 65 mm
- Max bar length
- 6.5 m (21')
- Laser power
- 3 kW
- Loading
- Manual, loader optional
| Specification | LXT-230Featured | LXT-65 |
|---|---|---|
| Best for | Heavy structural profile | Job shops, architectural tube |
| Tube diameter range | 20 - 230 mm | 12.7 - 65 mm |
| Max bar length | 8 m (26') | 6.5 m (21') |
| Laser power | 6 kW | 3 kW |
| Loading | Automatic bar loader | Manual, loader optional |
Applications
Industries We Serve
Tube Laser Cutting systems are trusted across diverse industries and production environments.
FAQ
Tube Laser Cutting Questions
Answers to common questions about our tube laser cutting products.
Round, square, rectangular and angle profile. The LXT-65 handles 12.7-65 mm round tube and matching square/rectangular sizes; the LXT-230 steps up to 230 mm round and heavy structural profile.
The LXT-65 runs on 400V/3-phase 80A; the LXT-230 needs 125A given its bar loader and higher laser power. Both need nitrogen and oxygen assist gas sized to your cutting volume.
Yes — setup, chuck changeover and tube-nesting training is included on-site, plus a test cut on your own tube stock before delivery.
We arrange lease and term financing through our equipment finance partners.
The tube laser, chuck, Lasoryx Vector control with nesting licence, rigging and installation, cut-quality commissioning, and operator/programmer training.
